Permanent Magnetic Separators

I. Product Series Overview

1. Suspended permanent magnetic separator

• Product Model: CX Series

• Applicable scenes: belt conveyor, vibrating feeder, down chute

• Working mode: continuous working system

• Execution standard: JB/T8711-2006

2. permanent magnetic self-discharging iron remover

• Product Model:RCYD series

• Application Scene ：Automatic iron removal production line

• Working mode ：automatic unloading continuous operation

• Optional Configurations: Explosion-proof type, high-temperature resistant type.

Second, the core technology features

1. Magnetic system design

• Composite magnetic system structure: NdFeB + ferrite composite magnetic circuit

• Magnetic field strength:

  • Suspended: ≥1200GS (surface)

  • Self-discharging type: ≥1500GS (peak)

• Magnetic Stability: 8 years demagnetization rate <5%

2. Mechanical structure

3. Control system

• Dual mode control:

  • Local manual control

  • Centralized automatic control (linked with the host)

• Protection grade:

  • Standard: IP54

  • Explosion-proof type: ExdIIBT4

Third, the comparison of technical parameters

Selection Guide

1. Suspended selection points

• Belt width matching: the width of the separator should be greater than the width of the belt 200-400mm

• Magnetic pole height: according to the material thickness selection (H = 1.5 × material thickness)

• Typical application:

  • Coal pretreatment

  • Primary selection of raw materials for building materials

  • Iron removal for grain processing

2. Self-unloading type selection points

• Unloading belt speed: 0.8-2.5m/s adjustable.

• Explosion-proof requirements: chemical industry, coal powder and other places need to choose explosion-proof type.

• Typical application:

  • Cement production line

  • Coal conveying system for thermal power generation

  • Mining crushing production line

Installation and Maintenance

1. Installation specification

• Hanging type:

  • Hanging angle ≤30°.

  • Height from the belt ≤ 80% of the rated value

• Self-unloading type:

  • Reserve ≥1.5m space on the side of unloading iron

  • Power supply box is ≤10m away from the equipment

2. Maintenance points

• Daily inspection:

  • Weekly removal of adsorbed impurities

  • Monthly check of bolt tightness

• Regular maintenance:

  • Test magnetic field strength annually

  • Replace bearing grease every 2 years

Six, industry solutions

1. cement industry

• Configuration: RCYD-12T explosion-proof type

• Installation position: raw material mill entrance

• Effect: Iron capture rate ≥98%.

2. Thermal power generation

• Configuration: CX-10 + metal detector linkage

• Installation Location: Coal conveyor belt transfer point

• Effectiveness: remarkable protection of coal mills

3. Mining industry

• Configuration: RCYD-8C weatherproof type

• Installation Location: Crusher front belt

• Effect: Reduce the crusher jamming fault by 90%.

Service Commitment

• Warranty: 5 years for magnetic system, 2 years for mechanical parts.

• Technical Support: Provide technical guidance for installation

• Spare parts supply: 24 hours delivery of commonly used parts

• Upgrade service: upgrading the magnetic system of the old model.

This series of permanent magnetic separator has become an important equipment for removing iron from materials in various industries by virtue of its strong magnetism, maintenance-free, long life and other characteristics. We can provide you with the optimal configuration according to your specific working conditions.
