Rare and precious metal ore production line and process solutions

Overview of Rare and Precious Metal Ore Beneficiation

Rare and precious metal ore beneficiation is an important extraction process for gold, silver, platinum, palladium and other metal resources with high economic value. Such ores are usually characterized by low grade, complex mineral composition, fine embedded grain size, etc., and require advanced technology and precise process flow to achieve efficient recovery. We provide a full set of rare and precious metal ore beneficiation solutions from ore analysis, process design, core equipment selection to production commissioning, and are committed to maximizing the economic benefits and resource utilization for our customers.

Applicable Minerals

This program is applicable to the following rare and precious metal minerals selection and extraction:

• Precious metals: gold, silver, platinum group metals (platinum, palladium, rhodium, iridium, etc.)

• Rare metals: lithium, beryllium, niobium, tantalum, zirconium, hafnium, etc.

• Rare earth metals: light rare earth, heavy rare earth minerals of all kinds

Rare precious metals beneficiation process

1. Crushing and screening stage

Adopting three stages and one closed-circuit crushing process, through the jaw crusher for coarse crushing, cone crusher for medium and fine crushing, and finally crushing the ore to -15mm or less, to provide suitable size of raw materials for the grinding operation.

2. Grinding and Classifying Stage

Ball mill and spiral classifier or hydrocyclone are used to form a closed-circuit grinding system to grind the ore to the appropriate fineness, so that the useful minerals can be fully dissociated, while avoiding the phenomenon of over-grinding.

3. Separation stage

Gravity separation process

• Application: for gold, silver and other high density precious metal minerals

• Equipment: shaking table, centrifugal concentrator, jigger

• Characteristics: low investment, low cost, no pollution

Flotation Process

• Application: applicable to the sorting of many kinds of rare precious metal minerals

• Characteristics: high sorting efficiency, strong adaptability

• Pharmaceutical system: customized special pharmaceutical formula according to the nature of the ore

Cyanide leaching (for gold, silver)

• Application: High-efficiency extraction of gold and silver minerals

• Process: Carbon slurry method or carbon leaching method is adopted

• Environmental protection measures: equipped with perfect environmental protection facilities to ensure that the discharge meets the standard

Magnetic separation process

• Application: for separation of minerals containing magnetic properties

• Equipment: high gradient magnetic separator, strong magnetic separator

Electrostatic separation process

• Application: used for the selection and purification of coarse concentrates.

• Characteristics: high sorting precision and stable effect

4. Concentrate processing stage

• Concentration and dewatering: adopting high-efficiency concentrator and filter.

• Drying and packaging: different drying methods are adopted according to product requirements.

• Smelting and purification: provide technical solutions for pyrometallurgy and wet smelting.

Advantages of Rare and Precious Metal Ore Production Line

1. High efficiency recovery rate

   • Adopting joint process and customized solutions for different mineral properties

   • Improve the recovery rate of useful minerals and concentrate grade.

2. Technical Advantage

   • We have professional engineers specialized in rare and precious metal ores

   • Exclusive rare and precious metal beneficiation technology ensures that the beneficiation indexes are up to standard and the revenue is maximized.

3. Flexible Adaptation

   • Individualized design according to the nature of the ore and processing capacity requirements

   • Modular design, easy to expand and renovate

Technical Service and Support

We provide a full range of technical support services:

• Ore selectivity test: Provide detailed rare metal ore dressing test and process mineralogy study.

• Process design: Determine the optimal rare metal beneficiation process based on the test results.

• Equipment Selection and Configuration: Provide the most optimized rare precious metal equipment configuration plan.

• Installation and commissioning: professional technical personnel on-site guidance equipment installation and commissioning

• Personnel training: Provide comprehensive operation and maintenance training.

• After-sales service: provide perfect after-sales technical support and service.

Successful Cases

We have successfully provided complete and efficient rare and precious metal production line solutions for many large-scale rare and precious metal mining projects at home and abroad. In a comprehensive rare and precious metal mining project, through the use of our unique joint extraction process, we not only realized the efficient recovery of gold and silver, but also successfully overcame the industrial separation and enrichment of platinum, rhodium and other rare and precious metals that are extremely difficult to extract, and realized the economic and stable recovery of platinum and rhodium, which helped the customer to greatly enhance the comprehensive utilization value of the resources and the overall economic benefits of the project.

Contact us: get rare precious metal ore beneficiation production line program and quotation!
