6-S Shaking Table

Product Overview

6-S shaking table is one of the core equipments of gravity beneficiation, which is widely used in the sorting of tungsten, tin, tantalum, niobium, iron, manganese, chromium, titanium, bismuth, lead, gold, and other rare and precious metal ores, as well as in coal mine sorting. The equipment is suitable for sorting operations of different grain sizes such as roughing (2-0.5mm), selecting (0.5-0.074mm), sweeping (-0.074mm), etc. The range of effective recovered grain size can be up to 2-0.022 millimeters when dealing with tungsten and tin ores.

6-S shaking table adopts glass fiber reinforced plastic bed, featuring high enrichment ratio and high sorting efficiency, easy operation and adjustment, and stable output of concentrate, middle ore and tailings, which is the ideal equipment for mine beneficiation.

Core Advantages

✅ High efficiency sorting

• High recovery rate & high enrichment ratio, precise separation of minerals with different specific gravity.

• Suitable for coarse sand, fine sand, sludge and other particle sizes.

✅ Flexible adjustment

• Adjustable stroke, adjustable lateral slope, adapt to different mineral requirements.

• Stable bed operation, stable sorting effect

✅ Durable

• Glass fiber reinforced plastic bed (7 different beds are available), wear-resistant and corrosion-resistant.

• Built-in spring design, compact structure, long service life.

✅ Easy to operate

• Convenient installation, intuitive adjustment, low maintenance cost.

Working Principle

Mineral particles are subjected to the inclined bed surface:

1. Gravity - to make the minerals stratified according to the specific gravity

2. Horizontal water flushing - separation of light and heavy minerals

3. Reciprocating movement of the bed surface - generating inertia force, strengthening sorting

Minerals with different specific gravity are distributed along the bed surface in a fan shape, and finally discharged from the concentrate end, the middle ore area and the tailing side respectively, realizing efficient separation.

Applicable minerals

• Precious metals: alluvial gold

• Non-ferrous metals: tungsten, tin, tantalum, niobium, lead

• Ferrous metals: iron, manganese, chromium, titanium

• Non-metallic minerals: coal

Why choose 6-S shaking table?

1. High sorting precision - minerals are separated precisely according to specific gravity

2. Strong adaptability - coarse sand, fine sand and sludge can be processed.

3. Energy saving and high efficiency--No need for complex power, low running cost.

4. Durable - glass fiber reinforced plastic bed surface is corrosion-resistant and has a long service life.
